JIS F2015 Cast Steel Chain StopperJIS F2015-1987 bar jinis chain stopper digawe saka cast steel.Iku piranti umum lan perlu kanggo mooring kapal.
Gambar saka JIS F2015-87 Cast Steel BarType Chain Stopper
|
Nominal No. |
Diameter Nominal Rantai Jangkar |
Ukuran (mm) |
Bobot (kg) |
|||
|
A |
B |
C |
D |
|||
|
40 |
38~40 |
378 |
540 |
390 |
336 |
111 |
|
44 |
42~44 |
412 |
590 |
424 |
366 |
139 |
|
48 |
46~48 |
450 |
640 |
460 |
397 |
176 |
|
52 |
50~52 |
491 |
695 |
494 |
428 |
216 |
|
56 |
54~56 |
528 |
745 |
530 |
457 |
261 |
|
60 |
58~60 |
564 |
795 |
564 |
488 |
319 |
|
64 |
62~64 |
600 |
850 |
600 |
517 |
380 |
|
68 |
66~68 |
635 |
900 |
636 |
547 |
452 |
|
73 |
70~73 |
675 |
960 |
678 |
582 |
561 |
|
78 |
76~78 |
715 |
1020 |
720 |
617 |
682 |
