Universal Fairlead Chain WheelUniversal Fairlead Chain Wheel: fairlead kanggo nuntun kabel liwat lan ngganti arah utawa matesi posisi ekspor, lan ngurangi gesekan antarane kabel lan lambung, utama Roller fairlead, cleat Roller fairlead, mbukak-jinis roller guide unit kabel, 360 ° Swivel fairlead lan liya-liyane.
Universal Fairlead Chain Wheel
Universal Fairlead Chain Wheel: fairlead kanggo nuntun kabel liwat lan ngganti arah utawa matesi posisi ekspor, lan nyuda gesekan antarane kabel lan lambung, utama Roller fairlead, cleat Roller fairlead, mbukak-jinis roller guide unit kabel, 360 ° Swivel fairlead lan liya-liyane.
Universal Fairlead Chain Wheel, kalebu krenjang, master silinder lan guide kabel tegese silinder utama ngandika bebas rotatable babagan sumbu tengah dibuwang ing proses krenjang , awak tubular utama kasedhiya karo bolongan liwat bebarengan sumbu tengah; piranti kabel guide kalebu loro plywood njaba lan Cut loro pesawat podo saka pulley juxtaposed antarane plywood, plywood tetep vertikal dibuwang ing lumahing ngarep silinder utama; nggunakake silinder master lan wheel dadi desain terpadu, struktur kompak, papan cilik, bisa gampang Applied kanggo prau cilik; Kangge, guide kabel saka sirah silinder bisa bebas muter sak sumbu utama, supaya fairleads keluwesan dhuwur kanggo nyukupi kabutuhan orientations beda saka guide kabel, nemen Ngapikake kacepetan fairlead, nyimpen akèh peralatan lan sumber daya pegawe; casing mburi ngarep plywood, supaya kabel permukaané , Nyingkiri pinggiran baja kanggo karusakan gesekan kabel.
|
Gambar No. |
Stok Sheave Timbal No. |
Diameter Sheave (ing.) |
Saben standar (ibs) |
Bobot Saben (ibs) |
Ukuran (in.) |
|||
|
A |
B |
C |
D |
|||||
|
461-18 |
239753 |
18 |
7/8 |
500 |
12.00 |
20.00 |
11.00 |
1.50 |
|
461-24 |
131574 |
24 |
1-1/4 |
500 |
15.00 |
26.00 |
14.00 |
1.50 |
|
461-26 |
238120 |
26 |
1-1/2 |
660 |
16.00 |
28.00 |
15.00 |
1.50 |
|
461-36 |
148389 |
36 |
1-5/8 |
850 |
20.00 |
36.00 |
19.50 |
2.00 |
|
461-40 |
136285 |
40 |
2 |
2006 |
23.00 |
42.00 |
22.50 |
2.00 |
|
461-42 |
130753 |
42 |
2-1/2 |
4000 |
28.00 |
52.00 |
25.50 |
2.50 |
|
463-26 |
4440359 |
26 |
1 |
988 |
33.00 |
33.00 |
3.75 |
1.50 |
|
463-30 |
1404377 |
30 |
1-1/4 |
1225 |
37.00 |
37.00 |
3.50 |
1.50 |
|
463-36 |
146522 |
36 |
1-1/2 |
1900 |
43.00 |
43.00 |
3.50 |
1.50 |
|
463-42 |
1406525 |
42 |
1-3/4 |
2975 |
50.00 |
50.00 |
4.38 |
2.00 |
|
463-48 |
131583 |
48 |
2 |
3600 |
55.00 |
55.00 |
4.63 |
2.00 |
|
463-60 |
123164 |
60 |
2-1/2 |
6400 |
68.00 |
68.00 |
5.75 |
2.00 |
